StruBIM Shear Walls

StruBIM Shear Walls designs and checks reinforced-concrete shear walls and coupling beams, including reinforcement, code verification, detailed reports and construction drawings.
Contact Sales

Vendor:

Category:

Software Intro

StruBIM Shear Walls is a structural engineering application for designing, editing and checking the reinforcement of reinforced-concrete shear walls and coupling beams. It can import structural geometry, internal forces and wall deflections from an Open BIM project or allow users to define and edit the elements directly.

Overview

StruBIM Shear Walls is a structural design application for reinforced-concrete shear walls and coupling beams.

The software can import geometry, internal forces and other analysis data from structural models such as CYPECAD, or users can define and edit elements manually. Engineers can design, modify and verify reinforcement according to the applicable structural standards.

Once the design is complete, StruBIM Shear Walls generates reinforcement details, code-verification reports, quantities and construction drawings. Results can also be shared through BIMserver.center for coordination with other disciplines and Open BIM project workflows.

Applications

  • Reinforced-concrete shear wall design
  • Coupling beam design
  • Reinforcement calculation and detailing
  • Structural code verification
  • Import of CYPECAD structural results
  • Internal force and deflection assessment
  • Reinforcement quantity reports
  • Construction drawings and documentation
  • IFC and Open BIM data exchange
  • BIMserver.center project coordination

Product Resources

Watch the official product video or download the technical datasheet for more detailed information.

Watch VideoDownload Datasheet
