StruBIM Embedded Walls

StruBIM Embedded Walls designs, analyses and checks diaphragm walls, piled retaining walls, mini-piled walls, sheet-pile walls and other embedded retaining systems.
Contact Sales

Vendor:

Category:

Software Intro

StruBIM Embedded Walls is a structural and geotechnical engineering application for designing and checking embedded retaining walls used in building and civil engineering projects. It supports diaphragm walls, piled and mini-piled retaining walls, steel sheet-pile walls and generic embedded-wall systems.

Overview

StruBIM Embedded Walls is a structural and geotechnical design application for analysing embedded retaining systems used in deep excavations and underground construction.

The software supports diaphragm walls, piled walls, mini-piled walls, sheet-pile walls and other embedded retaining systems. Engineers can define soil layers, groundwater conditions, excavation phases, anchors, struts and floor slabs to represent the actual construction sequence.

The program evaluates wall displacements, bending moments, shear forces, soil pressures and stability conditions throughout each construction stage. It can also generate reinforcement details, calculation reports and drawings, while BIMserver.center integration supports coordinated Open BIM workflows.

Applications

  • Diaphragm and piled retaining walls
  • Sheet-pile and mini-piled walls
  • Deep basement excavations
  • Underground structures and shafts
  • Multi-stage excavation analysis
  • Ground-anchor and strut systems
  • Soil and groundwater modelling
  • Stability and structural checks
  • Reinforcement and construction drawings
  • Open BIM project coordination

Product Resources

Watch the official product video or download the technical datasheet for more detailed information.

Watch VideoDownload Datasheet
