StruBIM Cantilever Walls

StruBIM Cantilever Walls designs, analyses and checks reinforced-concrete cantilever retaining walls, including wall geometry, reinforcement, foundations, soil conditions and stability.
Contact Sales

Vendor:

Category:

Software Intro

StruBIM Cantilever Walls is a structural and geotechnical engineering application for designing and checking reinforced-concrete cantilever walls used to retain soil. It automatically assists with the preliminary wall geometry, stem reinforcement and the geometric and reinforcement design of the wall foundation.

Overview

StruBIM Cantilever Walls is a structural design application for analysing and designing reinforced-concrete cantilever retaining walls.

The software allows engineers to define wall geometry, foundations, soil properties, groundwater conditions and external surcharges. It evaluates earth pressures and structural forces while checking the stability of the retaining system against sliding, overturning and bearing failure.

Required reinforcement can be calculated for the wall stem and footing, with the results presented through calculation reports and detailed construction drawings. This makes it suitable for retaining structures used in roads, buildings, landscaping and other civil-engineering projects.

Applications

  • Reinforced-concrete retaining walls
  • Road and highway retaining structures
  • Basement and building retaining walls
  • Earth-pressure analysis
  • Surcharge and groundwater modelling
  • Sliding and overturning checks
  • Foundation bearing verification
  • Wall and footing reinforcement design
  • Structural reports and drawings
  • Civil and infrastructure projects

Product Resources

Watch the official product video or download the technical datasheet for more detailed information.
